Dake Model SXC Work-A-Matic 110V Single Phase Gravity Feed Vertical Bandsaw with 9” Blade Travel 988040-1

Description

The Dake Work-A-Matic vertical bandsaw is a gravity feed saw that allows for hands-free operation.

Dake’s line of industrial strength, metalworking vertical band saws are engineered for long-lasting performance. Offering a model for every job and budget, you are sure to find a band saw that meets your shop’s needs. A robust frame construction reduces wobble and vibration assuring precise cuts with fewer errors. The Dake vertical bandsaws provide easy operation with years of trouble-free service.

Features

• Gravity feed. The blade feeds into the material by gravity, which allows for hands-free operation
• Fast set up. Effortless changes between a cut off saw, contour saw and rip saw. Fast set up makes it ideal for production
• Low voltage controls with thermal overload and E-stop for emergency stop and start situations
• Frame and base are heavy duty welded steel for rigidity. Built to handle the toughest environments
• Variable feed rate system with hydraulic feed regulator that features a convenient front mounted flow control valve
• Four blade speeds and infinitely adjustable blade pressure

Standard Equipment

• C-Clamp Assembly
• One Standard Blade
• Steel Base
• Cutting Chart
• Head Lock
• Miter Gauge
• Hydraulic Feed Control

Specifications

• Blade Width: ¼” - ¾”
• Blade Length: 120”
• Blade Speed: 70 / 140 / 270 / 540 fpm
• Blade Travel: 9”
• Band Wheels Number: 2”
• Band Wheels Size: 14” diameter
• Mitering: 45°
• Max Work Height: 14½”
• Worktable Dims: 29” x 18”
• Worktable Tilt: fixed
• Worktable Height: 36½”
• Electrical Requirements: 110V Single Phase 1HP
• Machine Dims: 29” x 40” x 66”
• Approx Weight: 810 lbs

Optional Add-Ons

• Heavy duty locking caster set
• Work lamp
• 3 TPI Bi-metal Blade
• 6-8 TPI Bi-metal Blade
