Edwards Manufacturing
Edwards Manufacturing Company is a family-owned business specializing in steel fabrication equipment since 1875. We lead the industry with our full line of high quality, low maintenance hydraulic Ironworkers that punch, notch, shear and brake steel plate, bar-stock and angle in a wide range of sizes to meet your needs. We support our Ironworker line with innovative hydraulic accessories and versatile tooling to fabricate rod, square stock, sheet metal and pipe. Our Ironworkers, Hydraulic Accessory Tools and Tooling Accessories are proudly MADE IN AMERICA with the highest quality American parts and materials. Our continual innovation, impeccable quality and competitive pricing speaks to the power of American manufacturing.
If you currently own an Edwards Machine and are in need of parts or service, please contact us. Elite Metal Tools offers price and availability on Edwards parts and service for most Edwards equipment.
- Punch: Max. Capacity 1-1/16" Dia. in 5/8" A36
- Flat Bar Shear: Max Capacity 1/2"x12" or 3/8"x14" Max. Thickness 3/4"x4"
- Angle Shear: Max. Capacity 4"x4"x1/4" or 3"x3"x3/8"
- Open Station: Dedicated For Optional Tooling
- CALL FOR MONTHLY SPECIALS! 281-241-9504
- Punch: Max Capacity 1" Dia. in 5/8" A36
- Flat Bar Shear: Max Capacity 1/2" x 10" | Max Thickness 3/4" x 4"
- Angle Shear: Max Size: 4"x4"x1/4" OR 3"x3"x3/8"
- Coper Notcher - Max Capacity 2"x3"x5/16"
- CALL FOR MONTHLY SPECIALS! 281-241-9504
- 2 Open Stations - One for punching and the other can be used as a coper notcher, multi shear, angle notcher, etc...
- Punch - Max capacity: 1" Dia. in 5/16" A36
- Throat Depth is 5"
- 1" Stroke
- CALL FOR MONTHLY SPECIALS! 281-241-9504
- Punch - Max Capacity 1" dia. in 3/4" A36
- Flat Bar Shear - Max Capacity: 1/2"x12" OR 3/8"x14" | Max Thickness: 3/4" x 4"
- Angle Shear - Max Capacity 4"x4"x3/8" OR 3"x3"x1/2"
- Coper Notcher - Max Capacity 2.5"x5"x1/4"
- CALL FOR MONTHLY SPECIALS! 281-241-9504
Precise, Repeatable Bends
- Punch: Max Capacity 1" Dia. in 1/2" A36
- Flat Bar Shear: Max. Capacity 3/8" x 10" Max Thickness 1/2" x 6"
- Angle Shear: Max. Capacity 3"x3"x1/4"
- Open Station: Dedicated for Optional Tooling
- CALL FOR MONTHLY SPECIALS! 281-241-9504
- Round Pipe: 2" Schedule 40
- Solid Round: 1.375"
- Angle Iron: 2"(.250")
- Standard Motor: 5 HP 3~ 208 V or 230 V
- Simple crank for inboard tool squaring
- Potential of tooling is only limited to your imagination
- accurate repeatability within 0.01"
- Connects to any edwards ironworker with the accessory pack
- Punch: Max. Capacity 1-1/2" Dia. in 1" A36
- Flat Bar Shear: Max. Width 1/2" x 24" Max. Thickness 1"x12"
- Angle Shear: Max. Size 6"x6"x1/2"
- Coper Notcher: Max. Capacity 2-1/2"x6"x1/2"
- Open Cavity: Dedicated for Optional Tooling
- CALL FOR MONTHLY SPECIALS! 281-241-9504
- 180 Degree Bend Capacity
- Smooth Fast Operation
- 2" (ID) Schedule 40 Pipe Capacity
- 2-1/2" (OD) .095" Tube Capacity
- 2-1/4" .083" Chromoly Capacity
Transform your shop press into a Brake. This Press Brake features our rugged, machined punch and 4-way die. The 4-way Press Brake die has the following dimensions 1/16", 1/8", 3/16", and 1/4".
- Punch: Max. Capacity 1-1/16" Dia. in 7/8" A36
- Flat Bar Shear: Max. Capacity 1/2"x14" Max Thickness 3/4"x10"
- Angle Shear: Max. Capacity 5"x5"x3/8"
- Coper/Notcher Standard
- CALL FOR MONTHLY SPECIALS! 281-241-9504
- Cyliner w/4" Bore, 2" Ram
- 6-1/4" Stroke
- Rolling Cylinder For Maximum Versatility
- Max. Working Area: 20" Wide x 10.5" Tall
- Max. Working Area: 38" Wide x 40.5" Tall
- Cylinder w/6" Bore, 4"Ram
- Rolling Cylinder For maximum Versatility
- 12-1/4" Stroke
Making repeatable bends?
Our adjustable Press Brake Back Gauge makes for easy set-up of repeatable bends. Simply bolt it up to the Edwards IronworkerBrake Tooling assembly or Press Brake Tooling for our 20 Ton Shop Press and 40 Ton Shop Press, and a simple hand crank glides the carriage backstop to your desired brake location.
- Punch: Max. Capacity 1-1/16" Dia. in 1" A36
- Flat Bar Shear: Max. Capacity 3/4"x14" Max. Thickness 1"x10"
- Angle Shear: Max. Size 6"x6"x1/2"
- Open Station: Dedicated for Optional Tooling
- CALL FOR MONTHLY SPECIALS! 281-241-9504
- Punch: Max. Capacity 1-3/8" Dia. in 1" A36
- Flat Bar Shear: Max. Capacity 3/8"x24", Max. Round 1", Max. Square 1", Work Height 37-1/2"
- Angle Shear: Max. Capactiy 5"x5"x1/4", Work Height 43-15/16"
- Notcher: Max.2-1/2"x6"x1/2"
- Open Tooling Cavity
- CALL FOR MONTHLY SPECIALS! 281-241-9504
- Punch: Max. Capacity 1-1/16" Dia. in 1" A36
- Flat Bar Shear: 1/2" x 18" | 3/4" x 14" | 1" x 10"
- Angle Shear: Max. Size 6"x6"x1/2"
- Coper Notcher: Max. Capacity 2-1/2"x6"x1/2"
- Rod Shear: Max. Round 1-1/2" Max. Square 1-1/4"
- CALL FOR MONTHLY SPECIALS! 281-241-9504
- IN STOCK, READY TO SHIP
- Punch - Max Capacity 1 1/6" Dia. in 3/4" A36
- Flat Bar Shear - Max Capacity 3/8"x24" | Max Thickness 1/2"x14" OR 1"x4"
- Angle Shear - Max Size 5"x5"x1/4" OR 4"x4"x3/8"
- Coper Notcher - 2 1/2"x6"x3/8"
- Open Station - For additional tooling
- CALL FOR MONTHLY SPECIALS! 281-241-9504
