Edwards Edwards 10 Ton Tube and Pipe Bender HAT1000

The Edwards 10 Ton Bender provides great flexibility to your shop. With over 300 dies available to bend pipe, tube, or square tube up to 180°, this Bender is a must have for any fabrication shop. Able to operate either Horizontally or Vertically depending on your project and with a heavy-duty rolling base, you can move the Bender out of the way when your project is complete. Must be run off an Edwards Ironworker with PowerLink ™ System or Portable Power Unit.

• 20' quick-connect hoses for simple "plug & play" operation
• Bend a wide variety of round or square tube and pipe up to 180°s
• Built-in storage on the frame keeps your Bender Dies conveniently close
• Easy-to-use hand/jog controls with integrated E-Stop
• Heavy-duty rolling stand allows you to move the Radius Roller around as needed
• Horizontal or Vertical operation provides the user flexibility
• Integrated proximity sensor and degree wheel ensure you make the right bend every time
• Over 300 standard dies available to handle your bending needs

Specification	Value
Tube Capacity (In.)	2-1/2 (OD) .095
Bend Capacity	180
Pipe Capacity (In.)	2 (ID) Sch 40
Stroke (In.)	14
Round Pipe Sch. 40 Capacity (In.)	2
Cylinder (In)	1-3/4" Ram
Round Tube Capacity (In.)	2-1/2
Square Tube Capacity (In.)	2 (OD) .25
Weight (Lbs.)	600
Rating (Tons)	10
Hydraulics (GPM)	3-1/2
Valve Pressure (PSI)	2750
Product Dimensions (In.)	40-1/2 x 36-1/2 x 42
Max. Bend (Deg.)	180
Overall Dimensions (L x W x H) (In.)	42 x 45 x 63
Net Weight (Lbs.)	600
Gross Weight (Lbs)	600
Height	63.0000
Length	42.0000
Weight	600.0000
Width	45.0000
