Ironwood

  • Sliding table length: 149”
  • Angle Capability - Crosscut miter fence: 0° – 49°
  • Cutting depth maximum (w/ 16” max. blade) for 90° cuts: 4.8"
  • Cutting depth maximum (w/ 16” max. blade) for 45° cuts: 3.34"
  • Sliding table length: 126”
  • Angle Capability Crosscut miter fence: 0° – 49°
  • Cutting depth maximum (w/ 14" max. blade) for 90° cuts: 3.93"
  • Cutting depth maximum (w/ 14" max. blade) for 45° cuts: 2.75"
  • Working width max.: 50”
  • Work piece thickness min.: 3/8”
  • Work piece thickness max.: 5.9”
  • Feed motor: 5 HP
  • Working width max.: 42”
  • Workpiece thickness min.: 1/8”
  • Workpiece thickness max.: 5.9”
  • Feed motor: 3 HP
  • Working width max.: 42”
  • Work piece thickness min.: 3/8”
  • Work piece thickness max.: 5.9”
  • Feed motor: 5 HP
  • Angle Capacity – Fixed Crosscut: 90°
  • Cutting depth maximum for 90° cuts: 3.93"
  • Cutting depth maximum for 45° cuts: 2.75"
  • Main saw motor: 3.7 kW (5 HP)
  • Number of pneumatic clamps: 3
  • Adjustable boring stroke: 2” – 4”
  • Max boring depth: 4”
  • Spindle speed: 3450 RPM
  • Sliding table length: 126”
  • Angle Capability - Crosscut miter fence: 0° – 49°
  • Cutting depth maximum (w/ 16” max. blade) for 90° cuts: 4.8"
  • Cutting depth maximum (w/ 16” max. blade) for 45° cuts: 3.34"
  • Max working width: 25”
  • Upper cutterhead motor: 25 HP
  • Lower cutterhead motor: 20 HP
  • Feed motor: 5 HP
  • Max. width of work piece: 25”
  • Max. thickness of work piece: 11.8”
  • Min. thickness of work piece: 0.39”
  • Feed motor: 1 HP
  • Saw blade size: 14”
  • Cutting capacity (thickness x width): 1” x 10”/ 2” x 9” / 3” x 8”
  • Saw blade speed: 4100 RPM
  • Motor: 5 HP
  • Spindle size: 1.25" x 6"
  • Speeds: 3000/4000/6000/8000/10000 RPM
  • Vertical spindle stroke: 6.3”
  • Spindle rotation: Forward/Reverse
  • Saw blade size: 20” / 22” / 24” (standard)
  • Cutting capacity (thickness x width): 2” x 21”/ 4” x 19” / 6” x 15” / 8” x 8”
  • Saw blade speed: 2400 RPM
  • Motor: 15 HP IE3
  • Minimum material length: 10”
  • Material thickness min.: 0.39”
  • Material thickness max.: 4"
  • Number of hold-down rollers: 6
  • Working width max.: 50”
  • Workpiece thickness min.: 1/8”
  • Workpiece thickness max.: 4.9”
  • Feed motor: 3 HP
  • Spindle size: 1.25" x 6"
  • Spindle tilt: 10° to -45°
  • Speeds: 3000/4000/6000/8000/10000 RPM
  • Vertical spindle stroke: 7.1”
  • Max cutting depth: 3/4"
  • Cutterhead speed: 5000 RPM
  • Positive stops: 45, 90, 135 degrees
  • Motor: 7.5 HP IE3
  • Max cutting depth: 3/4"
  • Cutterhead speed: 5000 RPM
  • Positive stops: 45, 90, 135 degrees
  • Motor: 5 HP IE3
  • Spindle size: 1.25" x 6"
  • Speeds: 3000/4000/6000/8000/10000 RPM
  • Vertical spindle stroke: 5.5”
  • Spindle rotation: Forward/Reverse
  • Maximum material size: 11.8” x 11.8”
  • Feed speed (variable): 0-82 ft/min
  • Saw wheel diameter: 24” x 2
  • Saw wheel drive: 20 HP
  • Sliding table length: 149”
  • Angle Capability Crosscut miter fence: 0° – 49°
  • Cutting depth maximum (w/ 14” max. blade) for 90° cuts: 3.93"
  • Cutting depth maximum (w/ 14” max. blade) for 45° cuts: 2.75"
  • Sliding table length: 102”
  • Angle Capability Crosscut miter fence: 0° – 49°
  • Cutting depth maximum (w/ 14" max. blade) for 90° cuts: 3.93"
  • Cutting depth maximum (w/ 14” max. blade) for 45° cuts: 2.75"
  • Max width of work piece: 32”
  • Max thickness of work piece: 11.8”
  • Min thickness of work piece: 0.12”
  • Feed motor: 2 HP
  • Working width max.: 50”
  • Work piece thickness min.: 1/8”
  • Work piece thickness max.: 4.9”
  • Feed motor: 5 HP

Ironwood woodworking machinery was designed for the modern craftsman, with a focus on increasing cutting accuracy, material yield and shop safety, while decreasing processing time, labor costs, and the need for rework. Designed by German and American engineers to meet and exceed the rising demands of the North American woodworkers, Ironwood strives to provide simple and innovative machinery solutions to improve any shops’ bottom line.

Ironwood is a division of Stiles Machinery, the industry-leaders in industrial woodworking machinery, and is backed by Stiles’ extensive network of technicians and comprehensive 24-hour technical support and parts availability.
