Stiles Machinery Ironwood 233V Two Headed 42” Wide Belt Sander S124RK

Description

Ironwood’s engineering team designed the S124RK two head wide belt sander to be a robust blend of innovation, dependability, and quality. Designed for a serious woodworker who demands absolute precision in sanding, this machine will save labor and deliver excellent quality results. The S124RK includes a steel contact roller on the first head and a combination head on the second head. All sanding heads feature poly-v belt drives and height adjustable contact rollers with position indicators for grit compensation, enabling quick set-up times and maximum stability, precision, and sanding quality.

Simple and Intuitive Controls

• Controller quickly adjusts machine thickness (+/- 0.1mm or 0.004”)
• Controller storage capacity of 99 programs for easy and fast adjustment
• Displays in mm or decimal inches (3 decimal places for inches)
• Simple push button controls for turning on and off each head
• Control switch with key for service or operation mode
• Amp meters for each sanding head
• Hour meter display
• Emergency stop

Sanding Heads

• 42” Two-head wide belt sander
• Head # 1 is a steel contact roller
  • 180 mm diameter profiled steel contact roller
  • Height adjustable contact roller with dial indicator for grit compensation
  • Twenty (20) horsepower motor
  • Poly-v belt drive
  • Cutting speed of 20 mps (65 fps)
  • Cutting direction against feed
• Head # 2 is a combination head
  • 130 mm diameter 65 shore profiled rubber contact roller
  • Height adjustable contact roller with dial indicator for grit compensation
  • Height adjustable sanding pad
  • Fifteen (15) horsepower motor
  • Poly-v belt drive
  • Cutting speed of 12 mps (40 fps)
  • Cutting direction against feed

Key Features

• Poly-v belt drive for all sanding heads for smooth and vibration-free sanding head operation
• Height adjustable contact rollers on all sanding heads with dial indicators for quick and easy setup and grit compensation
• Rubberized hold down rollers before and after each sanding head with double hold down rollers at infeed and outfeed for consistent hold down
• Variable speed conveyor 3.6-14 mpm (12 – 46 fpm)
• Conveyor table mounted on four heavy duty jack screws for smooth, stable and accurate height adjustment
• Adjustment hand wheel for quick and easy fine height adjustments
• Automatic conveyor belt tracking for worry-free conveyor belt operation
• Conveyor belt rides along robust steel conveyor table
• Electronic abrasive belt tracking
• Abrasive belt trimming for quickly and easily centering sanding belts for optimal sanding belt tracking
• Abrasive belt tensioning adjustment located on front of machine with safety switches for belt breakage
• Abrasive belt loading assist for all heads
• Abrasive belt run-off protection
• Pneumatic disc motor braking system
• Workpiece over thickness protection system
• Safety switches on all access doors and emergency stops at infeed and outfeed locations
• Infeed roller table with 2 infeed rollers
• Robust steel machine frame
• UL/CSA machine electrical components

Specifications

• Working width max.: 1070 mm (42”)
• Conveyor belt width: 1100 mm (43”)
• Abrasive belt width: 1100 mm (43”)
• Abrasive belt length: 1900 mm (75”)
• Workpiece thickness min.: 3 mm (1/8”)
• Workpiece thickness max.: 150 mm (5.9”)
• Workpiece length min.: 450 mm (17.5”)*
• Variable conveyor speed: 3.6 – 14 MPM (12 - 46 FPM)
• Feed motor: 3 HP
• Table rise/fall motor: ½ HP
• Head #1: 250mm Ø steel contact roller: 20 HP 65 fps belt speed
• Head #1: Rotation direction: Against feed
• Head #2: Combination head – 140mm Ø 65 shore rubber contact roller with felt pad: 15 HP 40 fps belt speed
• Head #2: Rotation Direction: Against feed
• Electrical connection*: 233V | 3 Phase | 60 Hz
• Dust collection requirements: 2,450 CFM
• Dust outlet –  head #1: 2 ports x 123 mm (5”)
• Dust outlet –  head #2 : 2 ports x 123 mm (5”)
• Compressed air requirements: 90 PSI
• Air consumption per cycle: 4 CFM
• Machine net weight: 2,300 kg (5,070 lbs.)
• Shipping dimensions (LxWxH): 84” x 85” x 89”

*Minimum workpiece length is based upon feeding one individual workpiece.

Abrasive belt starter kit included with machine (80, 100, 120, 150 and 180 grit)

**460V power upgrades available upon request.  Additional charges may apply.

Options

• Professional Installation
