Minimax

  • Maximum working length 47”
  • Maximum working length with copier 43”
  • Maximum working diameter (hand turning) 16”
  • Spindle speeds (RPM): 570 / 1,000 / 1,850 / 2,500

  • Main Blade Diameter: 12"
  • Main Arbor Size: 5/8"
  • Ripping Capacity, Right of Saw Blade: 50"
  • Fixed Table Size: 40" x 13"

  • 4.8HP Single-Phase (230v) Motor
  • Jointing Width: 16"
  • Max Planer Workpiece Thickness: 9"
  • Max Stock Removal: 1/8"

  • Table Dimensions: 98.4" x 43"
  • Gooseneck Depth: 32"
  • Gooseneck Height: 6"
  • Belt Width: 6"

  • 4.8HP Single-Phase (230v) Motor
  • Overall Table Length: 59.75"
  • Max Jointing Width: 12"
  • Max Planer Working Thickness: 9"

  • Jointer Working Width: 12"
  • Planer Maximum Working Thickness: 9"
  • Table Saw Rip Capacity: 32"
  • 3/4" Dado Capacity

  • Three Independent 2.5 HP Motors - 230v / 1 ph
  • Table Saw Blade Size: 10" Diameter with 5/8" Arbor
  • Jointer Width of Cutterhead: 10"
  • Shaper Spindle Working Length: 3"

  • Fixed Table Size: 33" x 22"
  • Max Cutting with Rip Fence: 50"
  • Main Blade Arbor Size: 5/8"
  • Main Blade Speed: 4,000 RPM

  • Table Saw Rip Capacity: 31.5"
  • Shaper Spindle Size: 3/4"
  • Jointer Working Width: 12"

  • Max. useful spindle length: 100mm
  • Max. tool diameter when profiling: 210mm
  • Max. tool diameter lowered under the table at 90°: 180mm
  • Max. tool diameter when tenoning: 275mm

  • Max. thickness of edges in strips: 5 mm
  • Min. panel length/width: 180/65 mm
  • Panel feed speed: 6 m/min
  • Worktable Height: 904 mm

  • XYLENT Cutterhead Standard
  • Maximum Jointing Width: 12”
  • Maximum Working Thickness: 9”
  • Motor: 230v / 1ph

  • Spindle spacing (center-to-center): 32mm
  • Worktable size: 905mm x 360mm
  • Worktable height: 900mm
  • Maximum bore, center-to-center: 640mm

  • Planer Max Stock Removal: 0.125"
  • Jointer Table Length: 78.5"
  • Table Saw Max Cut Depth: 3.75"
  • Shaper Spindle Diameter: 1.25"

  • Maximum spindle height above table 5”
  • Maximum tool diameter, profiling & under table 9”
  • Maximum tool diameter, tenoning: 12.375”
  • Sliding table stroke 51.25”

  • Worktable Dimensions: 2600 x 530 mm
  • Min. / Max. Panel Thickness: 16 / 50 mm
  • Feed Speed: 7 m/min
  • Max. Thickness of Edges in Strips: 5 mm

  • Fixed Table Size 33” x 22”
  • Sliding Table Size 10.6” x 102”
  • Squaring Stroke 5.5’
  • Table height 34”

  • Thickness of rolled edges: 0.4 - 3mm
  • Min. to max. panel height: 8 - 50mm
  • Feed speed: 7 m/min
  • Worktable dimensions: 3000 x 525mm

  • Three independent 2.5Hp motors – 230V
  • Blade size 12” diameter with ⅝” arbor
  • Swiss-made Tersa cutterhead in jointer/planer
  • Spindle working length 3”

  • Fixed Table Size: 33" x 25"
  • Table Height: 34"
  • Main Blade Speed: 4,000 RPM
  • Max Cutting Width with Rip Fence: 50"

  • Electrical: 230V 1 PH
  • Overall table length: 70.8”
  • Cutterhead speed: 5,000 RPM
  • Maximum stock removal per pass: 1/8”

  • Rollfeed Edge Thickness: 0,4 - 3 mm
  • Max. Thickness of Edges in Strips: 0.20 in
  • Min. / Max. Panel Height: 0.30 / 1.96 in
  • Worktable Dimensions:  118.10 x 20.66 in

  • 4.8 HP Motor (230v / 1 ph)
  • Jointer Working Width: 16"
  • Planer Max Working Thickness: 9.437"
  • Planer Min Working Thickness: 0.125"

  • Maximum blade diameter w/ scoring blade in place 12.4” (315mm)
  • Scoring blade diameter 100mm X 20mm
  • Maximum depth of cut 3.75”
  • Blade Speed Main (Scoring) RPM 4000 (8000)
