Dake Model SE912 110V Single Phase 9” Round Capacity Standard Duty Horizontal Bandsaw 983101

Description

Standard Duty horizontal bandsaw offering accurate cutting, rugged gear box, hydraulic control, chip brush blade cleaner, and wet or dry cutting with simple operation.

No tool takes more abuse than a horizontal band saw and nobody offers more dependable, more trouble-free horizontal bandsaws than Dake. Their heavy-duty, double-frame construction has been an industry standard since 1941. Since then, Dake’s four models of bandsaws have provided problem-free performance and maintenance-free operation, year after year.

Features

• Accurate cutting with vibration free cast/machined table bed, heavy steel base, horizontally mounted guide arms, and adjustable blade guides and rollers
• CE approved low voltage safety reset, thermos overload protection, auto shut off, blade guards, safety interlocks
• Quick release vise and hand wheel action for fast change of material sizes
• Wet/dry cutting
• Hydraulic control for head feed at variable rates to lock head at any height
• Convenient chip brush blade cleaner, storage in base and wheels that roll easily

Standard Equipment

• Recirculating coolant system
• Steel base with wheels
• Low voltage controls
• 6-8 TPI standard blade

Specifications

• Capacity
  • Solid Round 90°: 9”
  • Solid Round 45° Right: 3½”
  • Solid Rectangle 90°: 9” x 12”
  • Solid Rectangle 45°: 3½” x 7½”
• Max Blade Speed: 328 fpm
• Blade Width: 1”
• Blade Length: 104.5”
• Balde Speeds: 98 / 164 / 246 / 328 fpm
• Bed Work Area: 24½” x 9”
• Floor to Bed: 21¾”
• Horsepower: 1 HP
• Electrical Requirements: 110V Single Phase
• Machine Dims: 56” x 21” x 59”
• Approx Weight: 500 lbs

Optional Add-Ons

• 3-4 TPI Blade
• 10-14 TPI Blade
