Baileigh Industrial 5HP 220V Single Phase Industrial Planer with Helical Head IP-208-HH 1021087

Description

This 20”-wide helical head thickness planer can quickly turn rough lumber into boards with smooth faces. Heavy cast iron and steel construction keeps the material steady and supported.

Features

• 5 hp motor turns the cutter head at a whopping 5,000 rpm.
• Straight 4-row helical head cutter comes standard.
• Runs on 220-volt single-phase power, so it can work almost anywhere.
• Fully cast iron 20” x 25.75” table with 15” extensions can expand to an impressive 20” x 55.75”.
• 2 speeds allow you to pick what’s right for your project:
• 20 feet per minute when you need to smooth boards in shorter amount of time.
• 16 feet per minute when you want a more refined finish or you’re working with tougher material.
• 8” maximum and 0.25” minimum cutting height.
• Maximum 1/8” cut depth.
• Handwheel with a scale on the side of the planer lets you precisely adjust the height in seconds.
• Cast iron frame on the top and bottom stabilizes the machine and helps it last longer.
• Magnetic safety switch automatically turns the machine off in case of a power outage or a problem with the current.
• Anti-kickback fingers grip the material so it’s less likely to shoot back out if the blades get jammed.
• Extra-large 5” dust port prevents clogging. You can easily hook up your dust collection system, so your shop stays clean with breathable air.
• Built-in wheels on the base allow you to move the machine around your shop and store it.
• Covered by a 1-year parts warranty.
• Replacement parts are in stock at Baileigh’s Wisconsin warehouse for fast shipping.
• Lifetime technical support by phone means that you can call Baileigh’s team of experienced woodworkers whenever you have questions or need troubleshooting.

Specifications

• Item Number: IP-208-HH
• Shipping Weight: 920 lbs.
• Table Size (Length): 55-3/4"
• Table Size (Width): 20"
• Spindle Travel: 5000
• Maximum Depth of Cut (Resaw): 1/8"
• Cutter Head Diameter: 3-1/4"
• Max Stock Width: 20"
• Maximum Stock Height: 8"
• Minimum Stock Thickness: 1/4"
• Minimum Stock Length: 8"
• Feed Speed: 16/20 FPM
• Table Elevation: Manual
• Power: 220V Single Phase
• Horse Power: 5
• Weight: 880 lbs.
• Number of Inserts: 92
• Insert Rows: 4
• Shipping Dimensions (Inches): 60” x 48” x 55”
