Steelmax D1 Air ATEX 50CFM Low Profile 800W Portable Pneumatic Drill with Permanent Magnetic Base SM-D1-AIR-ATX

Description

The D1 AIR ATEX is an extremely small portable pneumatic drilling machine for cutting holes up to 1-3/8” diameter is hazardous environments and where access to the hole location is restricted. The D1 AIR ATEX conforms to the ATEX II 2 G/D c IIC T6/T4 standard for equipment used in hazardous environments.

A combination of pneumatic drive and permanent magnetic base eliminate the need of an electric power supply, thus making this machine an ideal solution in many hazardous environments such as offshore oil platforms, mining applications, shipbuilding, and petrochemical industries. The D1 AIR ATEX is one of the lowest height magnetic drills currently available on the world market.

Features

• 1-3/8” diameter x 1” depth of cut with annular cutters
• 5/8” diameter with solid twist drill bits
• For use in hazardous environments – fully ATEX compliant
• Low profile for use in height-restricted spaces
• Pneumatic drive and permanent magnetic base

Specifications

• Air Consumption: 50 CFM
• Air Pressure: 90 psi
• Motor Power: 800 W / 1.1 HP
• Arbor Size: ¾” Weldon
• Hole Diameter Range
  • Annular Cutters: ½”- 1-3/8”
  • Twist Drill Bits: 5/8”
• Maximum Depth of Cut: 1”
• Stroke: 1-9/16”
• Cooling System: through spindle
• Magnetic Base Holding Force (1” thick plate): 1461 lbs / 6.500 N
• Electromagnetic Base Dimensions: 3-1/8” x 7-1/16” x 1-7/16”
• Overall Dimensions: 18-7/8” x 6-5/8” x 7-1/16”
• Weight: 28 lbs 1 oz
