Safety Speed Portable Tabletop Screw Pocket Machine SPM101EZ

Description

Dubbed the SPM101EZ for its simplicity, the SPM101EZ Screw Pocket Machine is the newest addition to Safety Speed’s line of panel processing machinery.

The SPM101EZ screw pocket machine drills a pilot hole while machining a six degree screw pocket with dual routers and an easy action lever. An “EZ” action lever allows operators to pocket as material allows in two movements, without the need for finding a neutral position.

Features

• Machining a six-degree pilot hole and a screw pocket in one “EZ” motion.
• An “EZ” action lever allowing operators to pocket as quickly as desired
• Industrial built, yet 66lbs allowing for portability
• One switch that activates machine routers and includes emergency stops
• Fence Adjustments
  • Easily alter the distance that your pocket is drilled into the wood for a variety of screw lengths.
• Controlled Cut Speed
  • Mechanical action reduces air needed and makes the cut action smoother and cleaner.
• Pocket Alignment Guide
  • Align your panel and get an accurate pocket each time with our pocket alignment guide.
• CAM Linkage
  • Allowing both motors to move at the same time, reducing the cycle time without sacrificing cut quality.
• Pocket Depth Adjustment
  • Crank the handle on your machine to easily alter the pocket depth, ideal for the times that you’re working with wood of varying thicknesses. This process on the SPM101EZ requires hand tools to make the adjustment.

Specifications

• Pocket Motor: 1.75 HP
• Drill: 1 HP
• Router Motor Brand: Bosch Power Tools
• Router Collet Diameter: 1/2”
• Drill Collet Diameter: 1/4”
• Screw Pocket Angle: 6°
• General Usage: 1-3 hours per day
• Shipping Weight: 66 lbs. (30 kg)
• Dimensions: 25” x 15” x 22”

Options

• Dust Collection Chute
• Adjustable Material Stops
