Baileigh Industrial Dual voltage Single Phase 200A Inverter Stick Welder BW-200S 1021967

Description

The BW-200S from Baileigh Industrial is an industrial level 200 Amp Arc welder. It features extremely solid construction but remains very portable at only 16 lbs. This BW-200S Industrial welding machine is the ideal choice for a welder working at the job site in during extreme conditions.

Features

• Portable IGBT Inverter stick welder
• Dual voltage can run on 120 volt or 230 volt single-phase power
• Intelligent voltage sensing – This welder knows what voltage it is plugged into and (when plugged into 120V) will limit the output of the welder
• Step-less Current Adjustment - adjustments are infinite and do not “click” between only a few options
• Thermal Overload Protected, will shut down welding if its temperature is too high
• Fan Cooled
• Anti-Stick / Hot Start - automatically increases output at the beginning of a weld to pre-heat the weld and electrode
• Arc Force, keeps arc more stable, with less sticking, when the electrode is close
• Lift ARC TIG capable – Torch not included
• High Open Circuit Voltage
• Generator safe and will tolerate large voltage variations
• Easily sourced consumables
• Includes electrode holder, ground clamp, 6-50P 250V plug, and adaptor to 120V plug

Specifications

• Item Number: BW-200S
• Cooling System: Fan Cooled
• Maximum Current: 200 Amps
• Power: Dual Voltage - Dual Voltage - 120V/230V Single Phase
• Shipping Weight: 20 lbs.
• Rated Input Current: 20A (120V) / 40A (230V)
• Rated Input Capacitance: 4.4KVA (120V) / 9.2KVA (230V)
• No-Load Voltage: 78V (120V) / 78V (230V)
• Rated Working Voltage: 23V (120V) / 28V (230V)
• Welding Current: 15~75A (120V) / 12~200A (230V)
• Rated Duty Cycle: 100% (120V) / 15% (230V)
• 100% Rated Duty Cycle: 77A (120V) / 77A (230V)
• Efficiency: 85%
• Power Factor: 0.75
• Insulation Class: H
• Enclosure Protection: IP21S
• Special Notes: Includes electrode holder, ground clamp, 6-50P 250V plug, and adaptor to 120V plug
• Certification: CSA UL
• Shipping Dimensions (Inches): 18” x 10” x 14”
