Eastwood Elite 200 AMP Single Phase Multi-Process AC/DC MP200i Welder 65375

Description

Finally a TIG welder with professional features that can also MIG and Stick weld. Most multi-process machines are MIG units that only offer the option to TIG weld steel and its often scratch start without a foot pedal. Eastwood has raised the bar with this MP welder that not only has MIG and Stick options but is a fully functioning TIG machine with high frequency start and rocker style foot pedal so you can TIG weld steel, stainless, and aluminum. It’s like buying a quality TIG machine that can also MIG and Stick weld!

When you want a multi-process machine that’s built to deliver great results on both steel and aluminum with no compromises, you need the Eastwood Elite MP200i AC/DC welder. It has all of the features of a standard AC/DC TIG Welder like High Frequency Start and a Rocker Style Foot Pedal so when you switch from MIG to TIG you know you’re going to get the same great results you’d expect from a dedicated TIG machine.

When you’re doing a full-scale auto restoration, sometimes one welding function, whether it’s MIG or TIG, isn’t going to be enough. This machine is completely plumbed for MIG and TIG welding, and the cart holds a gas bottle for each so you can almost instantly switch between functions without changing hoses and regulators like you would with other units. That means everything stays connected and ready to weld, and with a flip of a switch you can go from MIG to TIG welding when you’re working on body panels, roll cages, customer fab parts, or other work.

Features

• MIG and TIG weld steel, stainless, and aluminum
• IGBT inverter based power supply
• MIG weld thin sheet metal to 3/8” thick steel and stainless
• TIG weld steel, stainless, and aluminum up to ¼”
• Arc weld up to 3/8” steel and stainless
• Weld aluminum up to ¼” with a spool gun
• Holds 4” or 8” wire spools (11 lb. max weight)
• Square wave inverter
• Fully independent MIG and TIG gas systems
• Holds 2 bottles for both MIG and TIG welding
• Rocker style TIG foot pedal with extra long cable (16’)
• Includes two gas regulators
• Dynamic cooling fan
• Side hooks for easy cable storage
• True AC/DC welder with foot pedal and high frequency start
• WP17 Flex Head TIG Torch included for greater flexibility
• Includes Gas Lens kit for improved performance
• Awesome Duty Cycles on all functions to keep you welding

Specifications

• Input Voltage: 240V, Single Phase, 50/60Hz
  • ​​Wired with a 240V male plug and has an adapter for 120V
• No Load Voltage: 68V
• Rated Input Current (Amps): MIG = 34.2, TIG = 25.7, ARC = 40.0
• Output Current Adjustment (Amps): MIG = 40-120, TIG (DC) = 5-200, TIG (AC) = 10-200, ARC = 20-200
• Duty Cycle: MIG = 40% @ 200 AMPS / 100% @ 130 AMPS, TIG = 50% @ 200 AMPS / 100% @ 140 AMPS, ARC = 40% @ 200 AMPS / 100% @ 130 AMPS
• MIG Wire Size: .023 to .035
• Power Factor: 0.73
• Efficiency (%): 80%
• MIG Wire Feed Speed (in/min): 35 – 590 Inches Per Minute
• Pre Flow Time (seconds): MIG 0, TIG 0.25
• Post Flow Time (seconds): MIG 1.0, TIG 0-30
• TIG Welding Starting Method: High Frequency Start
• Cooling Method: Dynamic Cooling Fan (only runs when required)
• Gas System: Fully Independent MIG and TIG systems
• Gas Flowmeter: Gas Flowmeter, CO2/Argon Compatible
• Welding Gas Bottle Capacity: Two 40-125 cu ft Cylinders
• Plug Type: NEMA 6-50P
• Wire Spool Sizes: 4” or 8” wire spools (11 lb. max weight)
• Dimensions: 35.20” x 19.88” x 30.28”
• Weight: 95.68 lbs.

Options

• Spool Gun (20172)
