Baileigh Industrial Dual Voltage Single Phase 200A AC/DC Pulse Tig Welder BW-200T 1021971

Description

The BW-200T is the ultimate 200amp AC/DC Welding Machine. With variable AC frequency and pulse welding it caters for the more technical aluminum jobs. It features a complete set of control functions to cater for the more demanding jobs and includes a stick function to add to its versatility. The BW-200T is the ideal AC/DC welder for the aluminum welding fanatic.

Features

• IGBT inverter
• Dual voltage can run on 120 volt or 230 volt single-phase power
• AC/DC
• Remote adjustment
• Pulse ratio and frequency
• Peak / base current
• Variable AC frequency / balance
• Thermal overload protected
• Fan cooled (on demand)
• Tig / Stick / Lift Arc
• 2 /4 step
• Pre / Post gas flow
• Up / Down Slope
• Variable arc force
• Generator safe
• Easily sourced consumables
• Includes TIG Torch, ground clamp, 6-50P 250V plug, adaptor to 120V plug, gas hose with regulator, and foot pedal

Specifications

• Item Number: BW-200T
• Cooling System: Fan Cooled
• Maximum Current: 200 Amps
• Power: Dual Voltage - Dual Voltage - 120V/230V Single Phase
• Shipping Weight: 64 lbs.
• Rated Input Current: 20A (120V) / 31A (230V)
• Rated Input Capacitance: 2.4KVA (120V) / 7.1KVA (230V)
• No-Load Voltage: 65V (120V) / 65V (230V)
• Rated Working Voltage: 22.6 (120V) / 26.4 (230V)
• Efficiency: 80%
• Power Factor: 0.8
• Insulation Class: F
• Enclosure Protection: IP21S
• MMA Rated Current: 20A~65A (120V) / 20A~160A (230V)
• TIG Arc Way: HF (120V) / HF (220V)
• Rated Current (DC TIG): 10A~95A (120V) / 10A~200A (230V)
• Peak Current (DC Pulse TIG): 10A~95A (120V) / 10A~200A (230V)
• Base Current (DC Pulse TIG): 50% Peak Current (120V) / 50% Peak Current (230V)
• Duty Cycle (DC Pulse TIG): 40% (120V) / 35% (230V)
• Pulse Frequency (DC TIG): 0.2Hz~200Hz (120V) / 0.2Hz~200Hz (230V)
• Rated Current (AC TIG): 20A~95A (120V) / 20A~200A (230V)
• Frequency (AC TIG): 50Hz~150Hz (120V) / 50Hz~150Hz (230V)
• Balance (AC TIG): 50%~85% (120V) / 50%~85% (230V)
• Peak Current (AC Pulse TIG): 20A~95A (120V) / 20A~200A (230V)
• Base Current (AC Pulse TIG): 50% Peak Current (120V) / 50% Peak Current (230V)
• Frequency (AC Pulse TIG): 50Hz~150Hz (120V) / 50Hz~150Hz (230V)
• Balance (AC Pulse TIG): 50%~85% (120V) / 50%~85% (230V)
• Pulse Frequency (AC Pulse TIG): 0.2Hz~20Hz (120V) / 0.2Hz~20Hz (230V)
• Duty Cycle (AC Pulse TIG): 40% (120V) / 35% (230V)
• Special Notes: Includes TIG Torch, ground clamp, 6-50P 250V plug, adaptor to 120V plug, gas hose with regulator, and foot pedal
• Certification: CSA UL
• Shipping Dimensions (L x W x H): 23” x 13” x 18”
