Steelmax MPB32 Pro 115V Single Phase Variable Speed Manual 32” Pipe Beveling System SM-PB-MPB-32-PRO

Description

The MPB 32 Pro Manual Pipe Beveling System from Steelmax will produce accurate weld preparation in minutes. As with all Steelmax pipe beveling solutions, the MPB 32 Pro will create highly repeatable and consistent fit-up, dramatically reducing cycle times and improving work flow.

The MPB 32 Pro mounts to the outside edge of pipe or tubing with a minimum outside diameter of 10”. In its standard configuration, the MPB-32 Pro can bevel pipe up to 32” in diameter. With an optional attachment, the MPB-32 Pro can bevel pipe of any diameter over 32”, making this an incredibly versatile solution. By attaching to the pipe’s circumference, the MPB-32 Pro compensates for out-of-round pipe and tubing and produces a consistent land dimension and bevel angle around the pipe. Outfitted with a heavy-duty, industrial motor with variable speed control, the MPB32 Pro turns at the optimal speed for efficient beveling of ferrous and non-ferrous pipes.

Features

• Simple set-up and operation
• Accurate bevel depth and bevel angle adjustment
• Complete weld preparation in a single pass (at 45°, max 15mm bevel width)
• Suitable for pipe thickness from 1/8” up to ¾”
• Both machines can be used to bevel plate as well
• Variable speed motor for optimized milling of various materials

Specifications

• Power supply: 115V / Single Phase / 60Hz / 2,400W
• Motor speed range: 1800-5850 rpm
• Pipe diameter range: 10” and larger
• Bevel angle range: 15-45°
• Max OD bevel width: 5/8” @ 45°
• Max bevel width: 13/16”
• Min pipe wall thickness: 1/8”
• Max pipe wall thickness: ¾”
• Weight: 41 lbs

Optional Accessories

• Pro pipe attachment for pipe diameters above 32”
• Cutter head assembly
• Cutting inserts
• Cutter wedge
• Cutter insert screw
