Laguna Tools M|Flux5 208V Single Phase 40.3 cu.ft. Wet Metal Dust Collector MCDCSDC-5
| Manufacturer Part: | EMT ID: |
|
MCDCSDC-5
|
19722
|
- Motor Speed: 3450 rpm
- Suction capacity: 3103 CFM
- Impeller size: 13”
- Outlet size: 6”
Description
The Laguna M|Flux5 Wet Metal Dust Collector is a robust and high-performance industrial-grade dust collection system designed specifically for metalworking applications. This machine enhances workplace safety by efficiently collecting metal dust and preventing hazardous dust particles from dispersing. Its water-based filtration system ensures maximum dust absorption, providing a clean and healthy work environment. Built with durability and convenience in mind, the M Flux 5 is equipped with a powerful 5 HP motor, a spacious collection drum, and user-friendly controls.
Ideal for professional workshops, the M|Flux5 is engineered to meet stringent safety standards and can handle demanding operations with ease. Its compact footprint and advanced filtration capabilities make it a valuable addition to any metalworking setup.
Features
- 208V Single Phase Motor
- 3450 RPM Motor Speed
- 5” Inlet
- 6” Outlet
Specifications
- Motor Speed: 3450 rpm
- Suction capacity: 3103 CFM
- Static pressure: 16.2” H2O
- Impeller size: 13”
- Inlet size: 5”
- Outlet size: 6”
- Switch type: magnetic switch
- Cubic feet: 40.3 ft³
- Electrical requirements: 208V Single Phase 5HP 60Hz 34Amp
- Machine Dims: 60” x 28” x 66”
- Approx weight: 494 lbs
| Manufacturer | |
| SKU |
MCDCSDC-5
|
| UPC |
195444297403
|
| Shipping Method |
LTL Freight
|
| Weight |
550 lb
|
| Dimensions |
65 × 35 × 70 in
|
