Edwards 65 Ton Ironworker 230V, 3Ph, with PowerLink IW65-3P230-AC600
10% Off Select Edwards Equipment
On Sale
*Image may display optional items not included with purchase.
You might also be interested in...
FREE SHIPPING
Limited Time Offer
MSRP: $36,179.51
Was: $29,869
Now: $26,882.10
Additional Savings: $2,986.90
| Manufacturer Part: | EMT ID: |
|
ED9-IW65-3P230-A
|
5696
|
- Adjustable electric stoke control
- Angle Shear blades have 2 corner radii for both thin and thick material and are made of precision tool steel with 2 cutting edges for extended life
- ANSI B11.5-1988(02) Compliant Guarding
- ETL Certified Controls
- Five Workstations: Standard (4) - Punch, Flat Bar Shear, Angle Shear, and Coper Notcher. Open Cavity (1): Customize your ironworker with four optional attachments including Brake, Rod Shear, Multi-Shear, and Pipe Notcher
The 65 Ton is the ultimate mid-range Ironworker. Flexible enough to handle a wide variety of projects, this 5 workstation machine is extremely versatile. It allows for fast and easy transitions between fabrication operations: punch, shear, notch, bend or cope all in one machine. Other features include an electric foot pedal with integrated jog control, bright LED lights to increase visibility and heavy-duty Made in USA steel construction. The PowerLink™ System increases your capabilities by turning your Ironworker into a power source for our line of Hydraulic Tools. Accepting 14 interchangeable Attachments and 17 Accessories allows an operator to improve productivity and accuracy.
- Adjustable electric stoke control
- Angle Shear blades have 2 corner radii for both thin and thick material and are made of precision tool steel with 2 cutting edges for extended life
- ANSI B11.5-1988(02) Compliant Guarding
- ETL Certified Controls
- Five Workstations: Standard (4) - Punch, Flat Bar Shear, Angle Shear, and Coper Notcher. Open Cavity (1): Customize your ironworker with four optional attachments including Brake, Rod Shear, Multi-Shear, and Pipe Notcher
- Flat Bar Shear blades are made of precision machined, high-quality tool steel with 4 cutting edges for extended life
- Integrated Lock-out/Tag-out system with multiple location E-Stop (foot pedal & control panel) for added safety
- Optimized workstation heights for improved efficiency
- Punches are easily changeable, long-lasting and available from 1/8" to 4" diameters along with square, oblong, hex, metric, and custom shapes
- Vertical movement produces even pressure resulting in precise punching and shearing with minimal distortion that results in extended tooling life
| Specification | Value |
|---|---|
| Motor Speed (RPM) | 1765 |
| Punch Max Capacity (In.) | 1-1/16 diam. in 3/4 mild steel |
| Punch Stroke (In.) | 1-13/16 |
| Punch Work Height (In.) | 36-9/16 |
| Flat Bar Shear Max Capacity 1/2" | 14 |
| Flat Bar Shear Max Capacity 3/8" | 24 |
| Flat Bar Shear Max Capacity (In.) | 3/8 x 24, 1/2 x 14, 1x4 |
| Flat Bar Shear Work Height (In.) | 34-1/2 |
| Flat Bar Shear Max Round Capacity (In.) | 1 |
| Angle Shear Max Capacity (In.) | 5 x 5 x 3/8 |
| Angle Shear Work Height (In.) | 43-1/2 |
| Weight (Lbs.) | 4750 |
| Coper Notcher Max Capacity (In.) | 2-1/2 x 5 x 3/8 |
| Flat Bar Shear Max Square (In) | 1 |
| Coper Notcher Work Height (In.) | 39-1/2 |
| Flat Bar Shear Max Round (In) | 1 |
| Hydraulic Pump (GPM) | 10-1/2 |
| Punch Shut Height (In) | 6-15/16 |
| Punch Open Height (In) | 8-3/4 |
| Amps | 22 |
| Hydraulics (GPM) | 10-1/2 |
| Rating (Tons) | 65 |
| Reservoir (Gal.) | 17 |
| Hydraulics (PSI) | 3500 |
| Hydraulic Reservoir (Gal.) | 17 |
| Valve Pressure (PSI) | 3500 |
| Motor (HP) | 7.5 HP 3 ~ 230V |
| Overall Dimensions (L x W x H) (In.) | 45 x 62-1/8 x 57 |
| Motor Amps | 22 |
| Shipping Dimensions (L x W x H) (In.) | 46 x 69 x 63 |
| Gross Weight (Lbs) | 4750 |
| Height | 63.0000 |
| Length | 46.0000 |
| Weight | 4750.0000 |
| Width | 69.0000 |
| Manufacturer | |
| SKU |
ED9-IW65-3P230-A
|
| UPC |
731325556612
|
| Shipping Method |
Flatbed
|
| Weight |
4,750 lb
|
| Dimensions |
46 × 69 × 63 in
|
| Country of Origin |
United States of America
|
