Burr King 2” x 72” Two Wheel Model 720 Variable Speed 120V Single Phase Probe Belt Grinder with Manual Tension 16110M

Description

The Model 720 presents a unique up front, two wheel, rear drive configuration that quickly accepts contact wheel finishing diameters from 3/8 inches to 3 inches in diameter. The Model 720 is equipped with a reliable and fully adjustable air pressure belt tension control system or manual tension system.

Using 1/2 inch to 2 inch belt width, the Model 720 72 inch belt track delivers long abrasive life coupled with excellent utility. Available in fixed or variable speed versions. Fixed speed models are recommended for 2" and larger diameter wheels.

Features

• Reaches deep into cavities
• Finish the I.D. of tubing
• Excellent for turbine blades
• Delicately blend finishes
• Rough away material
• Finish inside diameters
• 72" belt track
• Accepts 1/2 to 2 inch belt widths
• 1 inch diameter x 2 inch wide contact wheel.
• Heavy fabricated steel frame
• Out front grinding point with up to 14 inches probe capability (diameter dependent)
• Integrated dust collection shroud with 3 inch outlet
• Belt guard with belt access door
• Mount on a bench or pedestal (pedestal sold separately)

Specifications

• Variable Speed: 550-5500 SFPM
• Motor: 1.5 HP 120V Single Phase 50-60Hz
• Wheels: 2
• Contact Wheel Size: 1” x 2"
• Throat Clearance: None
• Contact Wheel Hardness: 55 Duro
• Manual Spring Belt Tension Quick Change Assembly: Yes
• Positive Belt Tracking Adjustment: Yes
• Overall Height, Width, Depth: 36" x 20" x 36"
• Safety Belt Guard: Yes
• Base Area: 8.5" x 8"
• Steel Backup Platen: None
• Adjustable Work Rest: None
• Construction: Solid Steel
• Bench or Pedestal Mounted: Yes
• Pedestal Included: No
• Main Application: Small Wheel Belt Grinding

Available Accessories

• Optional Pedestal Mounts
• Wide Variety of Front Wheel Options
  • Contact wheels from 3/8 to 3 inches in diameter with 1/2, 1, and 2 inch widths
• Magnetic Starter
• Larger Horsepower Motors
