$19,995
| Manufacturer Part: | EMT ID: |
|
M64
|
13846
|
- Max gauge: 24 ga
- Cut length capacity: 64”
- Eliminates burred edges and flying metal
- Shear is easily transportable
Description
The Hip and Valley Roofing Shear is the optimal metal roofing tool for cutting hips and valleys on your metal roof panels. The shear comes with one custom blade set. Each blade set is custom-made to accommodate a specific profile and pitch. The base of the shear is built to accommodate interchangeable blades. When needing to cut a different profile, additional blade sets are available to order. The shear is transportable, weighs 160 lbs. and designed and manufactured in the USA.
Blades Information
- Straight Blade: Will shear straight at 90* and do up to a 2/12 gable
- Valley Blades: A separate blade set will be needed for each valley angle
- Interchangeable Blade Sets: The blade sets can be changed to accommodate any manufacturers panel profile. Separate blades will be needed for each panel profile or to achieve various valley angles.
- Ideal For: Valley angles
Specifications
- Max Cut Width: Can shear exposed fastener panel up to 64″ in width
- Recommended Panel Thickness: 24 gauge
- Blades: Each shear comes with one set of blades attached to the shear. Blades are custom made to match the exposed fastener panel profile needed.
- Cuts Achievable: Can cut straight at 90* and up to a 9/12 valley with additional blade sets.
- Switching Blades: Switching between blade sets takes only a few minutes. All that is needed is 3/16″ Allen Wrench and 1/2″ wrench.
- Lifetime of Blades: Blades have been shown to last for thousands of cuts with proper care.
- Weight: 160 lbs
| Manufacturer | |
| SKU |
M64
|
| Shipping Method |
LTL Freight
|
| Weight |
160 lb
|
| Dimensions |
100 × 15 × 15 in
|
| Country of Origin |
United States of America
|
| Warranty |
2 Years
|
