Rikon Tools 1.5HP Variable Speed Drill Press with 6” Quill Travel & Digital RPM Readout 30-217
*Image may display optional items not included with purchase.
You might also be interested in...
Manufacturer Part: | EMT ID: |
30-217
|
14108
|
- Powerful 1.5 HP Motor
- Variable Speeds
- Clutch Depth Stop
- Cast Iron Table
Description
The 17” Variable Speed Floor Drill Press #30-217 is the best in the 17” class. Designed with features that woodworkers have demanded – more powerful motor, Vari-speed pulley that adjusts the chuck speed with a simple turning of a lever, speeds from 200-700RPM or 600-2300 RPM – a digital RPM display, rotating work table with clamp-friendly thin edges, large 6″ spindle travel, and a handy LED light.
Features
- Powerful 1.5 HP Motor
- Variable Speeds
- Clutch Depth Stop
- Cast Iron Table
Specifications
- Motor
- Horsepower: 1-1/2 HP
- Amps: 13.3/6.7
- Volts: 115/230V, 60Hz
- RPM: 1,720
- Swing: 17”
- Chuck Size: 5/8”
- Chuck Taper: JT3
- Drilling Capacity: 1”
- Spindle Travel: 6”
- Spindle Taper: MT2
- Head Rotates: 360°
- Speeds: Variable
- Speed Range: 200 – 700 / 600 – 2,200
- Quill Diameter: 2-5/8”
- Table Dimensions
- Table Size: 14” x 14”
- Table Tilts: 90°
- Table Rotates: 360°
- Maximum Chuck to Table: 27-3/4”
- Maximum Chuck to Base: 46-5/16”
- Column Diameter: 3-1/8”
- Overall
- Height: 70-1/8”
- Base Size: 19-7/8”x13-1/2”
- Net Weight: 192 lbs.
- Shipping Weight: 205 lbs.
- Shipping Carton: 60” x 27-1/4” x 10-3/16”
- Warranty: 5 Years
Manufacturer | |
SKU |
30-217
|
UPC |
814463012797
|
Shipping Method |
LTL Freight
|
Weight |
221 lb
|
Dimensions |
30 × 28 × 11 in
|
Country of Origin |
China
|
Warranty |
5 Years
|
