Rikon Tools 14” Deluxe Bandsaw with Tool Less Guides and Quick Adjust Drift Fence 10-326

Description

The 14” Bandsaw #10-326 is RIKON’s newest model with many Patented features that professionals will enjoy – including spring-loaded tool-less blade guides, quick-adjust fence system and quick-lock trunnion table angling system, plus, a quick release blade tension lever, large adjustment handles, hinged safety blade guard with sight window, high work table height, and storage cabinet base. Its dual voltage, 1-3/4HP motor provides ample power for most every work encountered. Designed with two speed options – just change the drive belt on the pulleys to change from fast to a slower blade speed. Includes 6” tall rip fence with re-saw bar. Wired for use with 3-wire 120V receptacles.

Features

• 13″ Cutting Capacity
• Patented – Spring Loaded Tool-less Guide System
• Patented – Quick Adjust Fence System With 6″ Tall Rip Fence
• Patented – Quick Lock Cast Iron Trunnion System
• 2 Speeds 1,445 / 2,950 FT / MIN.
• Large Cast Iron Table
• Balanced Cast Iron Wheels

Specifications

• Motor
  • Horsepower: 1-3/4 HP TEFC
  • Amps: 14/7
  • Volts: 115/230V, 60Hz, 1Ph
  • Blade Speed: 1,445/2,950 FT/MIN
• Cutting Capacity
  • Height: 13”
  • Width: 13-5/8”
• Blade (Includes 111” x 5/8”, 4 TPI, Reg.)
  • Width: 3/16” – 3/4”
  • Length: 111”
• Table
  • Size: 21-1/2” x 15-3/4”
  • Left Tilt: -7°
  • Right Tilt: 45°
  • Miter Gauge “T” Slot: (2) 3/4” x 3/8”
  • Height to Floor: 40-1/2”
  • Height to Base: 20-7/8”
  • Fence Size: 18-3/4” x 1-3/4” x 6”
• Overall
  • Height: 74-1/2”
  • Width: 33-3/4”
  • Depth: 25”
  • Base Size: 24” x 17-5/8”
  • Dust Port: 1@4”
  • Net Weight: 285 lbs.
  • Shipping Weight: 293 lbs.
  • Shipping Carton: 54-1/2”x17-7/8”x23-7/8”
  • Warranty: 5 Years
