Quantum Machinery Nargesa 220V Three Phase 70 Ton Industrial Hydraulic Iron Worker MX700

Description

The Quantum Nargesa MX700 Hydraulic Ironworker (Punching Machine) is widely-known for its extensive versatility. This unit can perform numerous working functions, such as punching materials (like sheet metal, flat bar, tube, angle, U profile, T profile, UPN, IPN, etc..) bending, cutting, inlaying, tube notching, embossing, and it doesn’t end there. The MX700 can be adapted to be used with tooling of any kind, even tooling that is made by you, the customer. If you’re looking for a versatile, efficient and easy to use workhorse, then the MX700 is an essential piece of equipment for your metalworking shop floor.

Quantum Machinery’s MX Series Ironworkers stand out in many ways but they are literally like no other Ironworker on the market, because of its displacement and the wide working table that allows you to fit all kind of tooling. Its versatility and features make it a fast payback machine. It carries out the same functions of 5 different machine. All Nargesa Hydraulic Ironworkers are equipped with Nargesa’s punching tool base that includes the fitting nut for punches and the base holder for dies.

Features

• The Displacement Adjustment allows for an increase in productivity
• There is no maximum dimension for punching
• Palletized Base to easily move the MX700 around
• Swinging front safety protection
• Start/Activation with safety pedal
• Digital display
• Part and strokes counter
• Alarm diagnosis
• One (1) punch and one (1) die from 0.120” to 1.10” are included
  • All other dies are available as optional add-ons

Punching Thickness Capacities

• Material Thickness: 1.0” Thick
  • Round Punch: 1.0” Diameter
  • Square Punch: 0.75”x0.75”
• Material Thickness: 0.39” Thick
  • Round Punch: 2.30” Diameter
  • Square Punch: 1.85”x1.85”
• Material Thickness: 0.31” Thick
  • Round Punch: 2.75” Diameter
  • Square Punch: 2.15”x2.15”
• Material Thickness: 0.19” Thick
  • Round Punch: 3.90” Diameter
  • Square Punch: 2.75”x2.75”

Specifications

• Hydraulic Power: 70 Tons
• Working Speed: 0.35” per second
• Return Speed: 0.55” per second
• Tooling Support Table: 23.6” x 13.7”
• Extremely Fast Tooling Changeover: 30 seconds max
• Gooseneck (Neck): 13.7”
• Max Height: 15.3”
• Motor Power: 7.5HP
• Electrical Requirements: 220V / Three Phase / 60 Hz
• Machine Dims: 37” x 52” x 82”
• Machine Weight: 4,400 lbs

 Optional Add-Ons

• Punches
• Dies
• Tooling
