| Manufacturer Part: | EMT ID: |
|
LBP.13
|
12623
|
- Pneumatic Model
- Spindle Speed: 3,450 RPM
- Length of Fence: 61.5-5-91.5 Inches
- Motor Specs: 1 HP, 110V, Single Phase
Description
All the same great features of the Manual version with the addition of the pneumatic system, the LBP.13 has a lubricated aluminum head, heat treated steel gears, 1 HP motor, 13 stainless-steel spindles, extendable fence guide up to 89” and 2 fence stops.
Standard Features
- Drill Bit Set Included
- Indexing Pins
- Adjustable X & Y Axis Flip Stops
- Spring Loaded Hold Downs
Specifications
- Motor Specs: 1 HP, 110 V
- Prewired: 110 V, Single Phase, 10 A / 5 A
- Table Size: 31”
- Spindle Speed: 3,450 RPM
- Fence Stops: 2
- Expandable Fence Guide: Max 89”
- Operation: Pneumatic
- Floor to Table Height: 34”
- Max. Depth of Stroke: 2.5”
- Length of Fence: 61.5-5-91.5”
- Number of Spindles: 13 (6 Left and 7 Right)
- Distance Between Spindle Centers: 32 mm
- Shipping Weight: 155 Lbs
| Manufacturer | |
| SKU |
LBP.13
|
| UPC |
7898531012837
|
| Shipping Method |
LTL Freight
|
| Weight |
155 lb
|
| Dimensions |
24 × 21 × 17 in
|
| Country of Origin |
China
|
| Warranty |
2 Years
|
