IMER Koine 4 220V Three Phase Continuous Pump and Mixer for Pumping and Spraying 1106304

Description

The Koine 4 continuous mixer - pump is designed to provide more volume and production. The Koine 4 is used almost exclusively for mixing and pumping wall grouts and self-leveling underlayments for those projects where you need tremendous production. The Koine series of pumps are quiet, perfect for indoor applications.

Standard Equipment

• Dust Grate with Vacuum port
• R8 Stator and rotor with tab
• Turbo mixer kit
• Material delivery pressure gauge
• Gear driven feed impeller
• Self-priming stainless steel water pump
• 35mm hose clean-out adapter
• Water system with flow meter and no freeze discharge valve
• 130’ electric cord
• 130’ water hose Ø 19 mm (3/4”)
• 33’ material hose Ø 35 mm (1-3/8”) with quick connects
• Integrated tool storage box
• Clean up kit (scraper and sponge)

Specifications

• Power: 220V/60Hz, 3 Phase
• Total machine power: 9 HP
• Mixing motor power: 7.5 HP
• Feeding impellar motor: 1 HP
• Water booster pump: 70 PSI boost
• Material flow rate: 140 cu ft/h
• Max. pumping distance: grouting/fireproofing 200 ft+
• Max. pumping distance: self leveling 300 ft+
• Gearbox speed: 400 RPM
• Loading height: 35.5in
• Dimensions width/length/h: 29W x 47L x 61.5H in
• Weight: 510 lbs

Optional Equipment

• Dual diaphragm compressor, 3 phase - Part # 1107640
• Koine gun kit - Part # 1107005
• 5’ overhead wand - Part #1107549
• 33’ x 35mm hose - Part # 1107528
• 35mm - 25mm Reducer - Part # 1107565
• R7 - 1.5 rotor with tab - Part # 1107625
• R7 - 1.5 stator - Part #1107624
• Mixing paddle for light materials - Part #1107541
• ​Spray gun 35mm female - Part # 1107641
