IMER Step-Up 120 Towable Electric Pump 220V Three Phase Motor 1106181
*Image may display optional items not included with purchase.
You might also be interested in...
| Manufacturer Part: | EMT ID: |
|
1106181
|
6304
|
- Motor power rate: 7.5 hp
- Electric compressor: 3 hp / 11 cfm
- Max aggregate size: 3/8 in
- Hopper capacity: 4.25 cu ft
Description
When you need more power to push through stiffer material, or you just need more volume, then look no further than the Step-Up 120 series of pumps. The IMER Step-Up 120 is a towable but very compact sized pump suited for very unique pumping situations and environments. These pumps are extremely versatile. Pump or spray mortars, stuccos, grouts, restoration mortars, underlayments, fireproofing, waterproofings along with many other materials.
Standard Equipment
- 2 speed Control panel
- 133’ power cord
- Remote control ready
- 5 h.p. / 7.5, 2 speed, 3 phase 100% duty cycle motor
- IM25L rotor/stator
- Tow kit
- 33’ of Ø 35mm hose with cam coupling
- 50MM to 35mm material hose reducer
- Grate for premixed materials
- Accessory tool box
Specifications
- Motor power rate: 7.5 hp
- Mixer power rate: 2 hp
- Max aggregate size: 3/8 in
- Maximum flow rate IM25L: 2.75 cu yd
- Maximum flow rate 60.12: 6 cu yd
- Maximum flow rate 2L6: 2.35 cu yd
- Horizontal pumping distance (*): 300 ft
- Vertical pumping distance (*): 200 ft
- Hopper capacity: 4.25 cu ft
- Dimensions: 33 W x 80 L x 38 H in
- Weight: 616 lbs.
Optional Equipment
- Spin 30 continuous mixer with iDust grate - Part # 1106152
- Step-Up 120 pan mixer, 3 phase - Part # 1107509
- Piston compressor, 3 phase - Part # 1107585
- 2L6 Rotor/stator kit - Part # 1107088
- 60.12 Rotor/stator kit - Part # 1107090
- Vibrating grate - Part # 1107593
- 33’ x 35mm hose - Part # 1107528
- 33’ x 50mm hose - Part # 1107533
- 50mm to 35mm material hose reducer - Part # 1106178
- 120’ Remote control - Part # 1107574
- Included with mixer - Part 1107509
- Non-towing wheel kit - Part # 1107633
- Spray gun step 120 - Part # 1107577
- Shotcrete gun - Part # 1106250
- 5’ overhead wand - Part # 1107549
- 16’ x 35mm male to 25mm male hose - Part # 1107074
- Pintle tow ring - Part # 1107161
- Electric compressor Part # 1107602
(*) The pumping distance will vary depending upon the type of material being used.
| Manufacturer | |
| SKU |
1106181
|
| EAN |
8033679032906
|
| Shipping Method |
LTL Freight
|
| Weight |
1,000 lb
|
| Dimensions |
48 × 85 × 50 in
|
