IMER Koine 35 220V Single Phase Continuous Pump and Mixer for Pumping and Spraying 1106315

Description

The Koine 35 pump from IMER is one of the most advanced and versatile production pumps on the market today. It is packed with features that allow it to do a variety of applications, yet is compact and highly portable making it perfect for interior or hi-rise building work. The only solution for the continuous mixing, spraying, and pumping of pre-blended cementitious and gypsum based mortars, stucco, fireproofing, self-leveling underlayments and grouts.

Standard Equipment

• Dust Grate with Vacuum port
• ​D8 1.5 stator and rotor
• Material delivery pressure gauge
• ​Control panel w/ exclusive IMER 4 speed inverter
• Self-priming water booster pump
• Water system with flow meter and discharge valves
• 66’ of power cord
• 66’ of water hose Ø 19 mm (3/4”)
• 50’ of material hose Ø 25 mm (1”)
• Hose cleaning kit with toolbox
• Mixing chamber clean out tool
• Air compressor ready

Specifications

• Power supply - 220V/60Hz, 1 phase
• Total machine power requirement HP 5
• Mixing and pumping motor HP 3
• Feeding impellar motor HP 1/2
• Electric compressor - 1HP
• Material flow rate Up to 60 cu ft/hr
• Maximum pumping distance 300 ft
• Loading height In. 36
• Dimensions width/length/height In. 62 x 27 x 47
• Weight Lbs. 510

Optional Equipment

• Dual diaphragm compressor -Part # 1107637
• Mortar, stucco and fireproofing gun kit -Part # 1107005
• D5 - 2.5 Rotor -Part # 1107085
• D5 - 2.5 Stator -Part # 1107084
• Turbo mixer (use with Part # 1107029 & # 1107028) -Part # 1107517
• 50’ x 25mm material hose - Part # 1107525
• 33’ x 25mm material hose - Part # 1107526
• 16’ x 25mm material hose - Part # 1107527
• 5’ overhead wand - Part # 1107549
• D8 - 1.5 Rotor with tab  - Part # 1107029
• D8 - 1.5 Stator - Part # 1107028
• ​SLU mixing paddle for light materials - Part # 1107597
