PRO-60G
|
10337
|
- Largest Beveler in the world
- Bevel up to 2 3/8″
- Angles from 20° – 50°
- Self-Propelled
Description
Introducing the larges and most powerful beveler in the world, the PRO-60G. The Pro-60G is a portable milling machine. This workhorse has the ability to bevel up to 2 3/8” and can handle material up to 3 1/2” thick. It features the ability to change the angle of bevel from 20 to 50°. Tool can be used stationary or will walk along the plate. 6 Tons of air pressure secures plate while being beveled. Variable speed spindle. Variable Speed feed rate. Materials such as Stainless, Hardox, Armor plate are no problem.
Features
- Largest Beveler in the world
- Bevel up to 2 3/8″
- Angles from 20° – 50°
- Self-Propelled
- Portable Milling Machine
Specifications
| Maximum Bevel Depth | 2 3/8″ |
| Maximum Material Thickness | 3 1/2″ |
| Minimum Material Thickness | 3/8″” |
| Milling Head RPM | 335-670 |
| Bevel-Angle | 20-50° |
| Motor | 5hp |
| Weight | 1800 lbs |
| Manufacturer | |
| SKU |
PRO-60G
|
| Shipping Method |
LTL Freight
|
| Weight |
1,800 lb
|
