Dake Model FG-75 220V Three Phase 3”x79” Belt Grinder 961003
*Image may display optional items not included with purchase.
You might also be interested in...
| Manufacturer Part: | EMT ID: |
|
961003
|
29
|
- Contact Wheel Size: 3” x 8”
- Belt Speed: 6000 fpm
- Grinding Plate: 3” x 21”
- Work Height: 22”-48”
Description
With 6,000 fpm grinding speed and a 4HP motor, Dake’s belt grinder is designed for maximum metalworking efficiency. The head pivots up and down for easy work height adjustments to adapt to the job at hand. A hinged top cover opens for access to grind large pieces of metal.
Features
- Pivots up and down on the base for easy ergonomic work height adjustments
- Advanced belt tracking with vented front wheel fixed in place for rigidity when grinding on the wheel radius
- Hinged top cover opens for access to grind large pieces using the entire length of the belt
- Adjustable parts rest and backing plate with Plexiglass shield to keep the part being ground steady and in place
Standard Equipment
- Base
- Hinged Cover
- Grinding Belt
- Plexiglass Guarding
- 60 Grit Belt
Specifications
- Belt Size: 3” x 79”
- Contact Wheel Size: 3” x 8”
- Belt Speed: 6000 fpm
- Grinding Plate: 3” x 21”
- Work Height: 22”-48”
- Base Dims: 17” x 21”
- Electrical Requirements: 220V Three Phase 4HP
- Machine Dims: 39” x 22” x 43”
- Approx Weight: 139 lbs
Optional Add-Ons
- Replacement Belt – 40 Grit
- Replacement Belt – 60 Grit
| Manufacturer | |
| SKU |
961003
|
| Shipping Method |
LTL Freight
|
| Weight |
277 lb
|
| Dimensions |
48 × 36 × 51 in
|
