Dake Model 14CX 120V Single Phase 14” Throat Variable-Speed Multi-Purpose Vertical Bandsaw MB14CX

Description

Dake’s line of industrial strength, metalworking vertical bandsaws are engineered for long-lasting performance. Offering a model for every job and budget. You are sure to find a bandsaw that meets your shop’s needs. A robust frame construction reduces wobble and vibration assuring precise cuts with fewer errors. The Dake vertical bandsaws provide easy operation with years of trouble-free service.

Features

• Disc brake with micro switch
• 110V outlet on back for optional light
• Window for safe blade tensioning
• Window for safe blade tracking
• Blade tension guide
• Worm gear & pinion upper guide
• 10 point ceramic guides
• Electronic variable speed
• Low blade speed: 60-1600 fpm
• High blade speed: 160-4400 fpm
• Dynamically balanced cast iron wheels
• Urethane single piece snap-on tires
• Cast table size: 21.5” x 16”
• Table tilt: 7°, ±45°
• Quick release blade tension
• Dust ports: 4” x 2”
• One bi-metal, metal cutting blade included

Standard Equipment

• Bi-metal blade

Specifications

• Blade Width: 1/8” - ¾”
• Blade Length: 115”
• Blade Speed (variable): Low: 60-1600 fpm, High: 160-4400 fpm
• Miter Slot: 3/8” - ¾”
• Band Wheels Number: 2
• Band Wheels Size: 14”
• Throat Size (Band to Column): 14”
• Max Work Height: 12”
• Worktable Dims: 21.5” x 16”
• Worktable Tilt: 7° Left / 45° Right
• Worktable Height: 38”
• Electrical Requirements: 120V Single Phase 1.75HP
• Machine Dims: 33” x 20.5” x 70.5”
• Approx Weight: 286 lbs

 Optional Add-Ons

• LED Bar Light (303852)
• LED Can Light (303815)
• Wheel Kit (MBA 14/12)
