Cosen 12.6” Semi-Automatic Horizontal Dual Post Mitering Band Saw SH-510LDM

Description

Cosen provides a full range of semi-automatic band saws in a wide variety of cutting capacities. These saws exceed many of the standard requirements that operators look for in a band saw machine. With its rigid construction and superior features, Cosen's SH-510LDM fits into that category. This heavy duty band saw offers precision, efficiency in operation, lower cost per cut, and durability in a demanding production environment.

Features

• High precision linear guide way design
• Heavy-duty cast iron swivel center features straight cutting and miter cuts (60 degrees)
• Gearbox designed to accept high lateral pressure (no thermal distortion)
• Adjustable flood coolant system
• Motor driven, synchronized wire blade brush
• Carbide blade guides and bearing provides additional blade support
• Cast-iron guide arms
• Cast-iron hydraulic vise which synchronizes movement with guide arm

Specifications

• Capacity:
  • 0° Angle:
    • Round: 12.6”
    • Rectangular: 13” x 20”
  • +45° Angle:
    • Round: 12.6”
    • Rectangular: 13” x 12.6”
  • +60° Angle:
    • Round: 7.9”
    • Rectangular: 13” x 7.9”
• Blade Speed: 82 - 328 FPM
• Blade Size (LxWxT): 16' 3" x 1.25" x .043
• Blade Motor: 3 HP
• Coolant Motor: 1/8 HP
• Workbed Height: 30.7"
• Weight: 3,097 lbs
• Floorspace (LxWxH): 97" x 100.4" 80.7"
