Revolution Machine Tools 3HP 22 Ton Horizontal Press HZ-FAB 22
*Image may display optional items not included with purchase.
You might also be interested in...
$25,895
$61,919.98
| Manufacturer Part: | EMT ID: |
|
HZ-FAB 22
|
14969
|
- Max Pressure at 200 Bar: 22 Ton
- Oil Tank Capacity: 3 Gal
- Max Stroke: 7.2"
- Bolt Diameter: 3"
Features
- All steel frame
- Stroke adjustment by DRO
- Manual working system
- All tooling and pins are induction hardened and ground
- Foot pedal operated
- Comes with 1 set of press brake tooling
- Brake gauge
- NC controller
Specifications
- Max Pressure at 200 Bar: 22 Ton
- Oil Tank Capacity: 3 Gal
- Bending Capacity
- Flat Material: 8" x 0.50"
- Round Tubes: 1.88" x 0.15"
- Max Stroke: 7.2"
- Bolt Diameter: 3"
- Tooling Height: 8"
- Operation Speed: 0.39 in/s
- Return Speed: 0.39 in/s
- Motor Power: 3 HP
- Net Weight: 1,170 lbs.
- Table Size (L x W): 18" x 41"
- Working Height: 43.3”
- Machine Length: 45"
- Machine Height: 47"
Options
- Automatic working system
- Cutting, punching, straightening, pipe bending tools
- CNC backstop
| Manufacturer | |
| SKU |
HZ-FAB 22
|
| Shipping Method |
Flatbed
|
| Weight |
1,450 lb
|
| Dimensions |
52 × 32 × 75 in
|
| Country of Origin |
Turkey
|
| Warranty |
1 Year
|
