PMK Systems Coping / End-Matching Machine with Quick Change Spindles and 8” Touch Screen Monitor C-1203 PLC / HSK
*Image may display optional items not included with purchase.
You might also be interested in...
| Manufacturer Part: | EMT ID: |
|
C-1203 PLC HSK
|
12807
|
- 30 seconds or less tooling change capability
- Two 7-1/2, 3 Phase, 230/460 volt motors
- Tool holder / Milling arbor 1.25″
- Unlimited Length of Part
Description
For the professional woodworker who puts quality first and wants the ability to do production. The C-1203 HSK Machine is used by cabinet door manufacturers who have 10 or more different profiles. Having the ability to be able to change tooling quickly is a must. With PMK’s system you can change your tooling in 30 seconds or less.
Features and Specifications
- Quick change spindles
- 8″ touch screen monitor
- 30 seconds or less tooling change capability
- Machine does a self-diagnosis of itself at start up
- (2) HSK Direct Drive spindles, 1 1/4″ Diameter, rotating 6,000-9,000 RPM, controlled by PLC & Touch screen monitor
- (2) 7 ½ HP, 3 Phase, 230/460 volt motors (please specify your voltage)
- Tool holder / Milling arbor 1.25″
- Comes with 4 HSK 63F tool holders
- Minimum part size is 3” long
- Max depth of cut is 3/4” depending on profile and density of the wood
- Length of spindle 55mm, 2.165″
- Unlimited Length of Part
- Small footprint – 60″ wide x 32″ deep x 64″ high
- Machine weight 1,469 lbs. (+/-)
| Manufacturer | |
| SKU |
C-1203 PLC HSK
|
| Shipping Method |
LTL Freight
|
| Weight |
1,469 lb
|
| Dimensions |
65 × 40 × 70 in
|
| Country of Origin |
United States of America
|
