Laguna Tools RPM5 220V Three Phase 66” x 12” Raised Panel Master Industrial Shaper MDM2050-0148

Description

Laguna is proud to introduce their latest Industrial Series machine, the Raised Panel Master 5. This machine is designed to allow a single operator to produce a complete cabinet door in less than 2 minutes. The single-piece welded steel frame provides the ultimate support for chatter-free work.

The heart of the machine is a shaper spindle with holds all five cutters needed to produce a door. The spindle is powered by a 10 HP motor for smooth cuts and is quickly positioned from the front of the machine with a dial. The turret system insures complete accuracy without test cuts and the pneumatically controlled spindle height is quickly set. The 2 axis sliding table rides on linear bearings in all directions and includes a pneumatic hold-down clamp for quick setup. The pneumatic EZ fence quickly positions stock for the next cut. A large diameter tracer bearing provides perfect control for straight and curved template following.

Features

• Motor: 10HP 220V 3-Phase w/VFD
• Speed range: 6000 to 8000 rpm
• Spindle: 1¼” diameter x 7¼” height
• Cutter capacity: up to 7” diameter

Specifications

• Table dimensions: 66” x 12.25”
• Cutter capacity: up to 7” diameter
• Spindle diameter x height: 1.25” x 7.25”
• Spindle speeds: 6000 to 8000 rpm
• Dust collection diameter (hood): 5”
• Job clamp: yes
• Tool kit: yes
• Compressed air requirement: 90 PSI 1 CFM
• Max material thickness: 1.25”
• Max arch height: 2” standard
• Max arch width: 24”
• Electrical Requirements: 220V Three Phase 10HP w/VFD
• Machine Dims: 52” x 38” x 54”
• Approx Weight: 1500 lbs

 Optional Add-Ons

• Carbide insert tooling
