GMC Machinery 10’ x 14 Gauge CNC Folder with 48’ ISA Back Table Gauge EFM-1014CNC
*Image may display optional items not included with purchase.
You might also be interested in...
| Manufacturer Part: | EMT ID: |
|
EFM-1014CNC
|
13732
|
- Capacity Mild Steel: 14 Ga
- Capacity Stainless Steel: 16 Ga
- Bending Length Capacity: 10’
- Max Table Back Gauge Distance: 48-3/8”
Features
- ISO 9001 certified
- Designed in US and Taiwan quality Machine
- Meet OSHA and CE safety standard
- ESA CNC control, made in Italy
- 16” large Digital glass touch screen
- Max. 99 bends per program
- Up to 2000 Programs Storage
- Profiles library with graphics
- Programmable Radius Bend
- Programmable Angle/ Angle Correct
- 48” CNC back gauge with table and fingers
- Hardened nose bar and table, up to 48HRC
- Comes with one 1” Insert Bar and one ½” Insert Bar
- Yaskawa Servo motors and Drives
- Schneider electrical components
- All steel construction for maximum rigidity
- Safety type foot pedal with handle and E-stop switch
- Safety 24V low voltage & overload protection
- One year industrial warranty for parts
Specifications
- Capacity Mild Steel: 14 Ga
- Capacity Stainless Steel: 18 Ga
- Bending Length Capacity: 10’1"
- Bend Angle Degree Programmable: 0-135°
- Large Beam Opening/Clamping Opening: 4-7/8”
- Min Reverse Bend: ½”
- Max Table Back Gauge Distance: 48-3/8”
- Min Table Back Gauge Distance: 1/2”
- Back Gauge Repeatability: 0.0039”
- Back Gauge Table Height: 35-3/4”
- Main Motor: 3 HP 220V 3-Phase
- Machine Weight: 9,850 lbs
- Machine Size LxWxH: 168 x 79 x 67
*This model can use a phase converter, but it must be installed at GMC. This will come with an additional cost*
| Manufacturer | |
| SKU |
EFM-1014CNC
|
| Shipping Method |
LTL Freight
|
| Weight |
10,150 lb
|
| Dimensions |
174 × 79 × 71 in
|
| Country of Origin |
Taiwan
|
| Warranty |
1 Year
|
