GMC Machinery 8’ x 10Ga 220V Three Phase Electric Power Shear with Manual Back Gauge EPS-0810M

Description

Shop GMC’s 8 foot mechanical shears that are capable of cutting up to 10 gauge mild steel and 14 gauge stainless. GMC’s sheering machines are designed as a low maintenance design with an array of features that will add value to any machine shop.

Features

• ISO 9001 certified
• American design and Taiwan quality machine
• HD all steel construction for maximum rigidity
• Precision driven gearbox
• Full length 30 strokes per minute
• 60” long squaring arm with inch/mm scale
• Spring hold-downs
• High grade carbon/chrome alloy steel blades and hardened to 62 hrc
• 2-edge indexable upper blade and 4-edge indexable bottom blade
• Full length with full view finger guard
• Front supports and (2) side gauges
• Safety type foot pedal control
• Jog, single continuous auto operation modes

Standard Equipment

• 26” manual back gauge with one side handwheel
• 60” long squaring arm with inch/mm scale, mounted on right side of the table
• 2 each 24” front support arms
• Full length finger guard
• Removable safety foot pedal control
• One set of upper & lower blades

Specifications

• Cutting Capacity
  • Mild Steel – HRS (tensile 60,000 psi): 8’ x 10Ga
  • Stainless Steel (tensile 85,000 psi): 8’ x 14Ga
  • Soft Aluminum (tensile 28,000 psi):  ¼”
  • Min thickness: 22Ga
• Blade length: 98”
• Strokes per minute: 26
• Worktable height: 32”
• Front support arm: 36”
• Back gauge (manual): 26”
• Blade rake angle: 2.5°
• Main Motor: 220V Three Phase 7½HP 25A
• Machine Dims: 124” x 43” x 68”
• Approx Weight: 6,650 lbs

 Optional Add-Ons

• Safety fence for enclosure of the back side of the machine
