GMC Machinery 4’ x 10 Gauge Heavy Duty Box & Pan Brake GMC-HBB-0410

Features

• Taiwan Machines
• ISO 9001 certified
• Hydraulic adjustment for opening
• Hydraulic power clamping for workpiece
• 26” manual back gauge with handwheel
• 1” manual beam adjustment (front and back)
• reverse bend is ¾” (20mm)
• Heavy welded all steel construction for maximum rigidity
• Hydraulic logic system centrally located and quiet
• A wide guide body ensures strong, stable, smooth & accurate movement
• Total pieces fingers assortment: 3”/ 3pcs, 4”/2pcs, 5”/5pcs and 6”/1pc
• Central control panels on each side for convenient operation
• Jog and auto operation modes
• Overload protection and disconnect switch

Standard Equipment

• Assorted fingers
• 26” manual back gauge with one side handwheel operation
• Angle set up dial
• Hydraulic clamping system
• Foot pedal control for hydraulic clamping & auto mode

Specifications

• Max Bending Length: 4’
• Capacity Mild Steel: 10 Ga
• Capacity Stainless Steel: 12 Ga
• Bend Angle Degree: 135°
• Max Box Depth: 6”
• Large Beam Opening: 3”
• Oil Tank: 10 Gal
• Main Motor: 5 HP
• Machine Weight: 4,150 lbs
• Overall Dimensions: 88 x 51 x 67
