Eastwood Elite QST 80/120 11HP Three Phase Scroll Air Compressor 32500
Manufacturer Part: | EMT ID: |
32500
|
18678
|
- Power Requirement: 208-240V Three Phase
- Motor Horsepower: 11 HP
- Motor RPM: 3516
- Sound Reading @ 10ft: 62 +/- 3 db
Description
Eastwood’s Elite 80/120 Scroll Compressor is ideal for the professional automotive repair and body ships. With its dependable, long-lasting construction and affordable price compared to other big brands, Eastwood’s R&D team have crafted the ideal air source.
Professional-level automotive shops will get the compressed air they need from a unit made to do the job right. The QST-80/120 is Eastwood’s most powerful yet quietest shop compressor yet. The innovative scroll technology performs like a 120-gallon compressor at a noise level of approximately 62 decibels, which is equivalent to a normal conversation or common household appliances such as air conditioners and dishwashers. You’ll no longer need to shout or use earplugs every time you fire up the compressor – just connect your tools and get to work.
With nearly 32 CFM of air output at 90 psi, the Eastwood QST Industrial Air Compressor can run several tools at once without a drop of sweat. It has an advanced air cooling and oil filtration system to maximize quality. This is one of the most dependable shop compressors ever; you never have to give it a break mid-project, and the pump life averages 100,000 hours.
This compressor must be used with a minimum of a 60 gallon air tank.
Features
- As low as 62DB +/- 3Bd at 1 meter
- Comparable in noise to your home A/C unit
- Quieter than your air tools
Specifications
- Power Requirement: 208-240V, 60Hz, 29.8-amp, three phase
- Motor Horsepower: 11 HP
- Motor RPM: 3516
- Sound Reading @ 10ft: 62 +/- 3 db
- Air Output: 31.8 SCFM @ 90 psi
- Requires External Air Tank: Yes
- Cut-In Pressure: 115 psi
- Cut-Out Pressure: 145 psi
- Maximum Pressure: 145 psi
- Pressure Relief Valve Setting: 160 psi
- Oil Capacity: 74 oz
- Dimensions (LxWxH): 33” x 19 ¾” x 36 5/8”
- Weight: 452 lbs
Manufacturer | |
SKU |
32500
|
UPC |
607174145645
|
Shipping Method |
LTL Freight
|
Weight |
500 lb
|
Dimensions |
44 × 24 × 38 in
|
