| Manufacturer Part: | EMT ID: |
|
DC-510CNC
|
6370
|
- Band Saw Blade Width: 2 x 0.063″ (54x1.6mm)
- Maximum Blade Length: 238-1/2″ (6060mm)
- Band Speed: 50-262 fpm (15-80mpm)
- Dimensions W x L x H: 122 x 94.5 x 102.5″ (3100x2400x2600mm)
Description
The DC-510CNC Hercules™ high production, horizontal CNC band saws from DoALL are highly efficient, automatic, hydraulically controlled machines with multiple material feeds. Designed for vertical cuts, the DC-510CNC is ideal for serial production in industrial settings. Thanks to the robust construction of the DC-510CNC it is possible to cut a wide range of full and profile materials including stainless and tool steel. In addition, the "box" or enclosed design provides very safe operation. A large variety of optional accessories are available to customize the machine for specific sawing requirements.
Specifications
Cutting Capacity Round (Tube or Solid): 20.08″ (510mm)
Cutting Capacity Rectangle: 20.08 x 22″ (510x560mm)
Maximum Bundle Capacity: 19.6 x 17.7″
Band Saw Blade Width: 2 x 0.063″ (54x1.6mm)
Maximum Blade Length: 238-1/2″ (6060mm)
Band Speed: 50-262 fpm (15-80mpm)
Band Drive: 10 hp (7.5kW)
Hydraulic Pump: 2 hp (1.5kW)
Coolant Pump: 0.16 hp (0.12kW)
Material Pass Line Height: 31-1/2″ (800mm)
Machine Weight: 13713lbs (6220kg)
Dimensions W x L x H: 122 x 94.5 x 102.5″ (3100x2400x2600mm)
Index Single Stroke Min-Max: 0.12-21.7″ (3-550mm)
Auto Index Multiple Stroke Max: 394″ (9999mm)
| Manufacturer | |
| SKU |
DC-510CNC
|
| Shipping Method |
Flatbed
|
| Weight |
13,713 lb
|
| Dimensions |
130 × 100 × 100 in
|
